Neptune / Trident Meter Service Notes

Measuring Chamber / Disc Data

  #3 Half Ball  1.183 Inches  (Standard)
  #4 Half Ball  1.184 Inches
  #5 Half Ball  1.185 Inches
  #6 Half Ball  1.186 Inches
  #7 Half Ball  1.187 Inches
  #8 Half Ball  1.188 Inches
  #9 Half Ball  1.189 Inches
#10 Half Ball  1.190 Inches

Parts Interchangeability (5/8 Trident)

Almost all Trident parts can be used in the Neptune Well-Flood meter, but only the measuring chamber from the split case version has the correct taper for the Well-Flood housing.
